         List of Products             Diode End Pumped Solid-state Lasers (532/473/671nm)


ST series: The laser head and power supply are separated. The output laser power is adjustable from 0 to maximum.



STB series: Laser head and the power supply are assembled together. The output laser power is not adjustable and is fixed at the maximum output laser power.

               Plug and play.






Green Lasers (532nm)


  Model: ST-532-ST-I/II/III (532nm-DPSS Green Laser-1~5000mW)


Model

ST-532-ST-I

ST-532-ST-II

ST-532-ST-III

Wavelength (nm)

532

Output Power (mW)

1~300 (-I)

300~800 (-II)

800~5000 (-III)

Working Mode

CW

Beam Mode

Transverse

TEM00

Longitude

Multi-longitude

Spectral linewidth (nm)

<0.1

Polarization

Line polarization

Polarization Ratio

>100:1

Beam Quality (M2 factor)

<1.2

Beam Divergence (full angle, mrad)

1.20.2

Beam Diameter at aperture (mm)

1.20.2

2.00.2

2.00.2

Beam roundness

>90%

Power stability(RMS)

<5% @8hours

Aperture Position (mm)

25

30

30

Dimensions of Laser Head (LWH, mm)

136 x 50 x 45

160 x 60 x 54

160 x 60 x 54

Driver Model

VD-I Series / VD-II Series

VD-III Series

VD-IV Series

External Modulation

5V TTL / 5V Analogue

Modulating Frequency

30KHz TTL / 10KHz Analogue

Cooling system

TEC

TEC

TEC + Air cooled

Warm-up time (minutes)

<15

Operation Temperature (℃)

18~30

Expected Lifetime (hours)

>10000

Warranty Time

1 year


Model: ST-532-ST-C1/C2 (532nm-Cylindrical-head Green Laser-1~100mW)



Model

ST-532-ST-C1/C2

Wavelength (nm)

532

Output Power (mW)

1~100

Working Mode

CW

Beam Mode

Transverse

TEM00

Longitude

Multi-longitude

Spectral Linewidth (nm)

<0.1

Polarization

Line polarization

Polarization Ratio

>100:1

Beam Quality (M2 factor)

<1.2

Beam Divergence (full angle, mrad)

1.20.2

Beam Diameter at Aperture (mm)

1.20.2

Beam Roundness

>90%

Power Stability (RMS, over 8 hours)

<15%

Laser Head

Dimensions (ΦH, mm)

Φ30 x 75

Net Weight (kg)

0.1

Integrated Driver Model

VD-I Series / VD-II Series

External Modulation

5V TTL / 5V Analogue

Modulating Frequency

30KHz TTL / 10KHz Analogue

Cooling System

None

Warm-up Time (minutes)

<15

Operation Temperature (℃)

18~30

Expected Lifetime (hours)

>5000

Warranty Time

3 months


  Model: ST-532-VBP-I/II/III (532nm-Portable Laser-1~250mW)



Model

ST-532-VBP-I/II/III

Wavelength (nm)

532

Output Power (mW)

1~250

Working Mode

CW

Beam Mode

Transverse

TEM00

Longitude

Multi-longitude

Spectral Linewidth (nm)

<0.1

Polarization

Line polarization

Polarization Ratio

>100:1

Beam Quality (M2 factor)

<1.2

Beam Divergence (full angle, mrad)

1.20.2

Beam Diameter at Aperture (mm)

1.20.2

Beam Roundness

>90%

Power Stability (RMS, over 1 hours)

<15%

Warm-up Time (minutes)

<3

Operation Temperature ()

18~30

Expected Lifetime (hours)

>5000

Warranty Time

3 months



  Blue Lasers (473nm)


Model: ST-473-ST-I/II (473nm-Blue Laser-1~200mW)






Model

ST-473-ST-I

ST-473-ST-II

Wavelength (nm)

473

Output Power (mW)

1~100

100~200

Working Mode

CW

Beam Mode

Transverse

TEM00

Longitude

Multi-longitude

Spectral Linewidth (nm)

<0.1

Polarization

Line polarization

Polarization Ratio

>8:1

Beam Quality (M2 factor)

<1.2

Beam Divergence (full angle, mrad)

1.20.2

Beam Diameter at Aperture (mm)

1.20.2

Beam Roundness

>90%

Power Stability (RMS, over 8 hours)

<5%

Noise of Amplitude (P-P)

<30%

Aperture Position (mm)

25

30

Laser Head

Dimensions (LWH, mm)

136 x 50 x 45

160 x 60 x 54

Net Weight (kg)

0.5

0.7

Integrated Driver Model

VD-I Series / VD-II Series

VD-III Series

External Modulation

5V TTL / 5V Analogue

Modulating Frequency

30KHz TTL / 10KHz Analogue

Cooling System

TEC

Warm-up Time (minutes)

<15

Operation Temperature ()

18~30

Expected Lifetime (hours)

>10000

Warranty Time

1 year


Red Lasers (671nm)


Model: ST-671-ST-I (671nm-Red Laser-1~150mW)





Model

ST-671-ST-I

Wavelength (nm)

671

Output Power (mW)

1~150

Working Mode

CW

Beam Mode

Transverse

TEM00

Longitude

Multi-longitude

Spectral Linewidth (nm)

<0.1

Polarization

Line polarization

Polarization Ratio

>4:1

Beam Quality (M2 factor)

<1.2

Beam Divergence (full angle, mrad)

1.20.2

Beam Diameter at Aperture (mm)

1.20.2

Beam Roundness

>90%

Power Stability (RMS, over 8 hours)

<5%

Aperture Position (mm)

25

Laser Head

Dimensions (LWH, mm)

136 x 50 x 45

Net Weight (kg)

0.5

Integrated Driver Model

VD-I Series / VD-II Series

External Modulation

5V TTL / 5V Analogue

Modulating Frequency

30KHz TTL / 10KHz Analogue

Cooling System

TEC

Warm-up Time (minutes)

<15

Operation Temperature ()

18~30

Expected Lifetime (hours)

>10000

Warranty Time

1 year


ST Series Diode Driver (power supply)



STD-I Series


Model

STD-I-P

Dimension (L x W x H)

100 x 63 x 55 mm

Weight

0.5kg

Input Voltage

DC 5V

Display

Unavailable

Current Adjustment

Available

External Modulation

5V TTL / 5V Analogue

Max Output Current

2.5A

Remark

Only PCB boards, for easier integrated into other systems



Model: STD-I-P (PCB power driver)


STD-II Series

Model: STD-II-N (normal power driver) Model: STD-II-O (power/current feedback driver)

Model: STD-II-L (power driver with safety lock) Model: STD-II-Q (passive Q-switched power driver)


Model

STD-II-N

STD-II-O

STD-II-L

STD-II-Q

Dimension (L x W x H)

160 x 140 x 83 mm

Weight

1.3kg

Input Voltage

DC 5V /\ AC 80-240V

Display

Current / Temperature

Current / Temperature / Laser Power

Current / Temperature

Current Adjustment

Available

External Modulation

5V TTL / 5V Analogue

5V 0~5KHz TTL

Max Output Current

2.5A

Remark

Suitable to drive 1~300mW lasers

With power / laser current feedback circuit, output power to be more stable and be displayed on the meter

With safety lock and interface interrupt part, to ensure user's security

Internal Modulation (05KHz), suitable to drive Passive Q-switched Lasers. External TTL modulation (0~5KHz) is also available


STD-III Series

Model: STD-III-N (normal power driver)

Model

STD-III-N

Dimension (L x W x H)

165 x 190 x 92

Weight

1.8kg

Input Voltage

DC 5V / AC 80-240V

Display

Current / Temperature

Current Adjustment

Available

External Modulation

5V TTL / 5V Analogue

Max Output Current

5.0A

Remark

Suitable to drive 300800mW lasers




STD-IV Series

Model: STD-IV-N (normal power driver)

Model

STD-IV-N

Dimension (L x W x H)

165 x 190 x 92

Weight

1.8kg

Input Voltage

DC 5V / AC 80-240V

Display

Current / Temperature

Current Adjustment

Available

External Modulation

5V TTL / 5V Analogue

Max Output Current

5.0A

Remark

Suitable to drive 800~5000mW lasers
